Stainless Steel Sanitary Tubing

Stainless Steel Sanitary Tubing
SEJIN TUBE TECH has grown to be one of the leading manufacturer and supplier for the welded Stainless Tubes such as ASTM A249, ASME SA249, Stainless Steel Pipes, Heat Exchanger Tubes, Light Gauge Stainless Steel Pipes, Stainless Steel Sanitary Tubing and Stainless Steel Seamless Tube

Dimension

- Specification : KS D 3585, JIS G 3447, ASTM A 270
- Usage : Tubes for dairy, food industry, medical appliances, etc.

KS D 3585 (JIS G 3447)						ASTM A 270
Out Diameter (mm)	Wall Thickness (mm)	Weight (kg/m)	Tolerance (mm)			Out Diameter (mm)	Tolerance (mm)
Out Diameter (mm)	Wall Thickness (mm)	Weight (kg/m)	Out Diameter	Wall Thickness	Length	Out Diameter (mm)	Out Diameter	Wall Thickness	Length
25.4	1.2	0.723	±0.15	±10%	+10 -0	25.4	+0.05 -0.20	±12.5%	+3.2 -0
31.8	1.2	0.915	±0.16			-	-
38.1	1.2	1.10	±0.19			38.1	+0.05 -0.20
50.8	1.5	1.97	±0.25			50.8	+0.05 -0.28
63.5	2.0	2.47	±0.25			63.5	+0.05 -0.28
76.3	2.0	3.69	±0.25			76.2	+0.08 -0.30
89.1	2.0	4.33	+0.30 -0.40			-	-
101.6	2.6	6.41	+0.35 -0.40			101.6	+0.08 -0.38
